100 Neo® implants + 100 Straight Abutments + ImplaKit® Starter Kit

Internal Hex System
Hex Size 2.42 mm
Standard Platform (SP)
Same Prosthetic Platform for all Implant Diameters Ø3.5 - Ø6.0 mm
Narrow Platform (NP) for Ø2.9 / Ø3.3 Implant - Hex size 2.1 mm
Implant Diameters: Ø3.3 /Ø3.5/ Ø3.75 / Ø4.2 / Ø5.0 / Ø6.0 mm
Implant Lengths: Implant Lengths: 6 / 8 / 10 / 11.5 / 13 / 16 mm
Abutment Lengths & Collar Heights: L8.5 - H1 / L9.5 - H2 / L10.5 - H3 / L11.5 - H4 mm
Material: Titanium Ti-6AL-4V-ELI
Premium quality designed medical grade autoclavable plastic box.

Tools Included

Ratchet wrench
Short Ratchet Hex driver 2.42 mm
Short Ratchet Hex driver 1.25 mm
Short Low-speed Motor mount 2.42 mm
Short Low-speed Motor mount 1.25 mm
Short Hand Hex driver 1.25 mm
Long Hand Hex driver 1.25 mm
Short Parallel Pin
Long Parallel Pin
Marking Drill 1.9 mm (MDL)
Twisted Drill External Irrigation 2.0 mm (Pilot)
Twisted Drill External Irrigation 2.5 mm
Twisted Drill External Irrigation 2.8 mm
Twisted Drill External Irrigation 3.2 mm
Twisted Drill External Irrigation 3.65 mm
Twisted Drill External Irrigation 4.2 mm
Twisted Drill External Irrigation 5.2 mm
Drill Extension

NEO® Implant Structure

NEO® is a unique system based on the traditional and proven design of tapered, threaded, balanced Implant with dynamic self-drilling capabilities. NEO® is an outstanding tapered implant with a symmetrical structure that contributes to balance efforts and has an equal distribution of possible loads during implantation.

ImplaKit® Surgical Kit - Instructions for Use & Maintenance

Maintenance and cleaning

The sterilization boxes must be cleaned before each use. Always use mild detergents even if cleaning is done using a piece of ultrasonic equipment.
Dry the boxes with a soft cloth. Do not use abrasive sponges or metal parts that might damage the surface of the box.

WARNINGS

The boxes are NOT supplied in a sterile condition and then the user must provide for sterilization before use.
Before sterilization is necessary to make sure that the boxes have been cleaned, in all its parts, from residual contaminants.

How to sterilize

The materials used for the production of the boxes can withstand a high number of sterilization cycles. The user must comply with the parameters defined for the main standard autoclave cycles without exceeding the maximum values set:› Max time 20 minutes› Maximum temperature 135 °C› Maximum pressure 2.2 bar

Storage

The material may change the color tone on prolonged exposure to UV light. Store the trays in a dark place when not used.
